“These results will be clinically useful, because we provide a new opportunity for mechanism-based treatment for chronic, widespread muscle pain resulting from recurrent acid insults possibly associated with symptoms of fibromyalgia and myofascial pain syndrome.” Chen et. al.


How the transition from acute to chronic pain occurs is the million dollar question in fibromyalgia

The question what causes acute pain or fatigue to turn into chronic pain or fatigue is on the minds of researchers everywhere. Some are finding clues in the central nervous system.

Lloyd found that a genetic predisposition to increased immune activation in concert with high symptom levels plays a role in the transition from short-term fatigue to long term. Now, we continue our PEM series with a study seeking to uncover the molecular causes of the transition from short-term to chronic pain in the muscles. They used a mouse model of fibromyalgia to do  it.

Not Pain By Any Other Name…

Like fatigue, pain is a multidimensional concept. In a recent blog we saw that the fatigue found in multiple sclerosis is fundamentally different from the fatigue produced in chronic fatigue syndrome, and pain is no different.

Studies indicate that hypersensitive pain states produced by inflammation, chemotherapy, and muscle vibration are relayed through certain types of pain receptors (IB+ receptors) and involve a switch in certain intracellular signaling pathways (from PKA to PKC).  The hypersensitive pain conditions that are associated with exertion and muscle activity found in disorders such as fibromyalgia and chronic fatigue syndrome may, however, involve different molecular pain pathways.

Giving Mice Fibromyalgia


Laboratory animals have it tough, but they play an essential role in research.

Animal models have played a key role in understanding how this occurs. It turns out that it’s not that hard to produce an FM-like state in rodents. You simply inject them twice over five days with an acidic saline solution in a muscle.  Not only do they develop prolonged pain, but the pain is now widespread and is accompanied by the same kind of sympathetic nervous system activation found in chronic fatigue syndrome and fibromyalgia.

Inflammation Takes a Back Seat

With studies unable to find evidence of inflammation in the muscles in people with FM, researchers have tended to look elsewhere – in particular, in the central nervous system.  Inflammation, however, may not be necessary. Studies suggest that problems with the sensory nerves, particularly the ion channels found in those nerves, could be enough.

Muscle Metabolism to the Fore

The ion channels that detect increases in proton levels that occur during tissue acidosis appear to be involved. As proton (H+) levels rise as muscles get fatigued, these ion channels tell the neurons to relay pain signals to the nervous system. If this happens often enough, central sensitization – a hypersensitive response to pain at the level of the spinal cord and central nervous system  can occur.

Roles of ASIC3, TRPV1, and NaV1.8 in the transition from acute to chronic pain in a mouse model of fibromyalgia. Wei-Nan Chen, Cheng-Han Lee, Shing-Hong Lin, Chia-Wen Wong, Wei-Hsin Sun, John N Wood and Chih-Cheng Chen. Molecular Pain 2014, 10:40 http://www.molecularpain.com/content/10/1/40


Increased activity in specific ion channels causes long term pain in mice

In this mouse study, researchers attempted to determine how metabolites produced by the muscle during exertion produce long-standing muscle pain in two ways. First they developed mice with different combinations of ion channels, then injected them with an acidic saline solution that mimicked a muscle metabolite produced during exercise. After observing which mice the acid solution sent into pain for long periods of time, they were able to determine how that pain is produced molecularly.

They found that two ion channels found on muscle pain receptors; the “acid-sensing ion channel 8” (ASIC3) and “transient receptor cation channel 6” (TRPV1) needed to be activated in order to produce increased pain. ASICs are cationic channels found on neurons that are activated by extracellular protons.

Producing Long-lasting Pain

Increased activation of these channels in conjunction with increased current in NaV1.8 voltage-gated sodium channels produced longstanding pain.  Finding that mice without NaV1.8 sodium channels experience short term pain sensitization (2 to 4 days) but never the long-term pain type of pain (14-19 days) found in FM and ME/CFS, it became clear that the sensory neurons containing these ion channels are responsible for long-term states of muscle pain [presumably in response to exercise].

Nav1.8 ion channels are found the dorsal root ganglion [that we know herpesviruses like to hang out in] and in small unmyelinated sensory neurons called C-fibers [that may be being affected by small fiber neuropathy in fibromyalgia]. Nav1.8 ion channels are considered to be key targets for new drugs to treat increased pain sensitivity and allodynia.

Treatment Implications

Although ASIC3 plays an important role in priming and triggering a state of chronic pain sensitization, it does not appear to be involved in maintaining it.  This suggests that ASIC3 antagonists such as APETx2 could be helpful in preventing sensitization before it happens, but not after a person is in a chronic pain state.


Drugs that block the activity of specific ion channels may be able to stop long term pain

Increased activation of the NaV1.8 sodium channels, on the other hand, appear to play a key role in maintaining a chronic state of acid-induced muscle pain. These voltage-gated ion channels determine how excitable the peripheral nerves are.

This suggests that sodium channel blockers could that block NaV1.8 sodium channels could stop the long term muscle pain seen after exertion in some disorders.  The authors noted that sodium channel blockers such as mexiletine or lamotrigine are a possibility, but they focused on a NaV1.8-selective antagonist (A-803467) that blocks NaV1.8  sodium channels from telling the sensory nerves to ramp up pain signals.

They believe this type of selective sodium channel blocker might be a good choice to treat chronic muscle pain that’s associated with recurrent ischemic insults; i.e. pain associated with the kind of low blood flow states that studies indicate may be found in ME/CFS and possibly FM.

A sodium channel blocker, A-803467, was introduced by Abbot laboratories in 2007 as a neuropathic and inflammatory pain blocker. Several aspects of A-803467 suggest it might helpful in FM and/or ME/CFS.  A-803467 reduces the autonomic nervous system’s “pressor response” to lactic acid.

Amytriptyline is an antidepressant widely used to combat migraine and pain.  A recent study suggests that its effectiveness may be due to its ability to block NaV1.8 sodium channels.


Implications for Chronic Fatigue Syndrome and Fibromyalgia

The authors do not explicitly link their findings to the post-exertional malaise problems found in fibromyalgia and chronic fatigue syndrome, but they’re clearly focused on how the development of very long duration muscle pain associated with acid induction (i.e., exercise) occurs.


The results from the Light ME/CFS studies line up with these results

The lack of inflammation in the muscles of FM patients has led many researchers to dismiss the muscles and focus on the central nervous system. This research indicates, however, that inflammation is not necessary to produce chronic muscle pain.

Long-term muscle pain can be produced by problems with acid-sensing ion channels found on the neurons in the muscles.

This study suggests  (if I have it right ) that long-lasting muscle pain can be produced and maintained by the same muscle by-products (protons) that Newton’s research suggests are being produced in high quantities in ME/CFS patients after exercise.

It indicates that the two ion channels implicated in post-exertional malaise in ME/CFS (ASIC3 and TRPV1) prime the system for the long-term pain,  and that sodium channel upregulation ( NaV1.8) plays a critical role in producing it.

That presents the possibility that blocking the activity of these sodium channels could resolve it.

Studies by the Lights Agree

The Lights are trying to understand how both the production of fatigue and pain occurs after mild exercise in ME/CFS. Fatigue appears to be produced first and then pain is produced as PEM worsens. Instead of looking at mice, though, they’re examining the patient’s blood after exercise to determine gene expression of the receptors associated with these ion channels.

ASIC3 was one of the several receptors found to be upregulated in ME/CFS patients with and without fibromyalgia after exercise in the Lights’ gene expression studies.  This upregulation was highly associated with increased physical and mental fatigue and pain.  Most recently TRPVI activation after exercise helped to differentiate the postexertional malaise found in ME/CFS from the fatigue found in multiple sclerosis.  ASIC expression was significantly greater in ME/CFS patients with FM.
