Not Only Central Sensitization
Fibromyalgia (FM) has long been thought to be a central sensitization disorder – a disorder primarily characterized by a hypersensitivity to pain and other stimuli. Fibromyalgia doesn’t just increase one’s sensitivity to pain, though. It’s also associated with a host of other symptoms that the central sensitization hypothesis may not explain very well, including unrefreshing sleep, cognitive problems, gut issues and anxiety.
One group of symptoms that has gotten little attention in fibromyalgia are those that arise or get worse during standing such as: dizziness, lightheadedness and fainting, as well as fatigue, pain and cognitive problems.
These symptoms can manifest with something as dramatic as fainting or as innocuous as simply feeling the need to lie down, having more trouble thinking or talking when upright, or having more trouble with upright exercises such as walking.
Other signs that one is having problems being upright can include feeling the need to move when standing still or putting one’s legs up on something when sitting. I’ve never been diagnosed with a specific kind of orthostatic intolerance, but I’ve noticed that my best posture for speaking on the phone is lying down on my back with my legs up the wall.
Every time we stand, we have to counteract gravitational forces which want to drain our blood to our feet. Our bodies counter those forces in several ways. The blood vessels in the lower part of our body constrict and the muscles in our legs tighten up to help keep blood from pooling there. The autonomic nervous system plays a large role in keeping us functioning when upright.
Symptoms that get worse when standing are associated with a condition called orthostatic intolerance (OI). In the constellation of diseases that one associates with OI, such as chronic fatigue syndrome (ME/CFS), postural orthostatic tachycardia syndrome (POTS), and Ehlers Danlos Syndrome, FM is kind of the odd man (or woman) out with regard to OI.
It seems strange that such an important part of these other diseases would not show up in FM. That oddity prompted a search through the medical literature to determine if orthostatic intolerance is present in fibromyalgia, and if it is, what that means regarding the disease.
The Orthostatic Intolerance Story in Fibromyalgia
The OI story in fibromyalgia starts 20 years ago with a researcher, Peter Rowe MD, who would become well known for work on the role orthostatic intolerance plays in chronic fatigue syndrome (ME/CFS). What isn’t well known is that one of Rowe’s earliest OI studies involved fibromyalgia.
That 1997 study – still the only FM study Rowe ever worked on – found abnormally large drops in blood pressure when FM patients were given a tilt table test. (Tilt table tests involve strapping the participant to a “table” and then tilting them up and measuring how their cardiovascular systems respond). That drop in blood pressure presumably resulted in reduced blood flow across the body, but particularly in the brain – sometimes causing feelings of dizziness, lightheadedness or even fainting.
Another study that same year by Dr. Martinez-Lavin – who would go on to produce a hypothesis of sympathetic nervous system dysregulation in FM – found evidence that standing provoked a “sympathetic nervous system derangement” in FM. Martinez-Lavin’s study would set the stage for a series of studies which validated a state of sympathetic nervous system hyperactivity in FM.
The next study to use the tilt table to test autonomic nervous system functioning in FM came in Martinez-Lavin’s small 1999 study, which proposed that the lupus-like features in fibromyalgia might very well result from autonomic nervous system problems.
Then in 2000, Satish Raj (another doctor and researcher who would later achieve prominence in the dysautonomia/POTS field) – in his sole FM publication – found that 65% of FM patients tested positive during a tilt table test and exhibited signs of dysautonomia (malfunction of the autonomic nervous system).
Meanwhile, numerous studies were finding evidence of low heart rate variability (HRV) in FM – indicating that a sympathetic nervous system hyperactivity accompanied by a parasympathetic nervous system withdrawal was present in FM.
In 2002, one report suggesting that low blood volume was present in fibromyalgia provided another potential link to orthostatic problems in FM. When the body has less blood available, standing can result in even larger drops in blood flow to the brain. Low blood volume is a common finding in chronic fatigue syndrome (ME/CFS) and POTS and contributes to the orthostatic intolerance in those diseases.
In 2005, Staud came right out and said what the studies had been pointing to: doctors should use tilt table testing to evaluate fibromyalgia patients. Staud found a pattern of abnormally rapid heart rate; i.e postural orthostatic tachycardia syndrome (POTS) in his FM patients. He postulated that the fatigue, dizziness and palpitations often seen in FM are likely the result of autonomic nervous system problems.
That same year, an Italian group did the most comprehensive tilt table assessment of the autonomic nervous system yet in fibromyalgia. The small study (n=32) found that besides the expected low HRV readings and higher heart rates, higher muscle sympathetic nervous system activation was present during rest. That finding suggested that the sympathetic nervous system hyperactivity found was making “rest” not so restful.
The group found high rates of fainting (44%) on the tilt table test. The reduced muscle, sympathetic nerve and vagal activity during the tilt test suggested that both parts of the autonomic nervous system – the sympathetic and parasympathetic nervous systems – were pooping out during the stress of tilting.
The autonomic nervous system problems in FM were linked to increased pain sensitivity. A 2010 Spanish study then linked problems with blood pressure regulation during a stress test with increased pain. Besides the low HRV readings, problems with blood pressure regulation and baroreflex sensitivity (which is involved in blood pressure regulation) were associated with greater pain sensitivity. Plus, stroke volume – which can reflect problems with preload – was reduced as well.
While a tilt table was not used, the study suggested that all it took to impact cardiovascular functioning in FM was a mental exercise test. That study hearkened back 10 years to findings showing that people with “idiopathic orthostatic intolerance“; i.e. people who experience lightheadedness, fatigue, heart pounding, etc. upon standing tend to have lower cardiac vagal baroreflex sensitivity, lower blood volume and increased heart rates upon standing. By 2010, each of these (baroreflex sensitivity, reduced blood volume and increased heart rates) had shown up in FM studies.
The very next year, another Spanish study validated those same findings. A cold pressor stress test (applying a cold stress, usually by plunging the hand into ice water) indicated that a whole raft of cardiovascular factors (resting stroke volume, myocardial contractility, R-R interval, heart rate variability, and sensitivity of the cardiac baroreflex) were reduced in FM, even at rest.
Then, when put under stress, the FM patients’ autonomic nervous systems failed to respond adequately. It was as if after being “on” all the time, the ANS, exhausted, collapsed during stress. Once again, problems with blood pressure regulation (baroreflex sensitivity) were associated with increased pain sensitivity.
Next, a Brazilian group demonstrated that the autonomic problems in FM extended to the ability to exercise. They showed that chronotropic incompetence – the inability to increase the heart rate normally during exercise – was common in FM. They, too, noted during stress the strange combination of sympathetic hyperactivity while resting, and a kind of sympathetic nervous system collapse (a “hyporeactivity to stress”). Intriguingly, they suggested that problems with B-1 adrenergic receptors – the same receptors to which autoantibodies have been found in POTS – might be responsible.
They proposed that autonomic nervous system problems could be contributing to a long list of symptoms (sleep disorders, chronic pain, allodynia, anxiety, pseudo-Raynaud’s phenomenon, sicca syndrome and intestinal irritability) in FM. Interestingly, they suggested that exercise – a helpful therapy in both FM and POTS – could help ameliorate some of the autonomic nervous system problems. Indeed, one study found that resistance exercise resulted in improvements in vagal tone in FM.
In 2014, Mayo Clinic researchers reported that the ‘Compass’ autonomic nervous system self-report test indicated that FM “patients frequently report lightheadedness that is triggered by upright posture, warm temperatures or stressful events which may indicate the presence of orthostatic intolerance.” This should, they suggested, trigger a clinical evaluation of an orthostatic disorder using a tilt table test. Plus, they proposed that the problems with sweating, the inability to tolerate heat, the dry eyes, the light sensitivity, the bladder and bowel problems and sleep difficulties sometimes found in FM could all derive from autonomic nervous system issues.
In 2015, problems with blood pressure regulation again came to the fore. A New York study found that diastolic blood pressure (DBP) was significantly inversely correlated with baseline fibromyalgia impact (FIQ) scores, even during quiet sitting. Since blood pressure plays a crucial role in forcing blood flow into our tissues, the association between DPB and FIQ scores suggested that cardiovascular issues were having a direct impact on FM.
In a statement that could have been taken right out of several POTS studies, the authors proposed that problems with the muscle pump and “fluid pooling” in the lower extremities “may be playing a critical role in the development of FM symptoms.” This pooling, they proposed, results in “reduced venous return” – precisely what Dr. David Systrom is finding in his large group of exercise intolerant patients.
The authors asserted that blood pooling in the lower extremities could explain why fibromyalgia has so many symptoms in common with hypotension (fainting, dizziness, headaches, fatigue, pain, depression, anxiety).
Finally, in 2017 a Spanish group found that problems with the cardiac baroreflex (which regulates blood pressure) during standing were strongly associated with reduced quality of life and an increased fibromyalgia impact score. They proposed that the problems FM patients were encountering being upright were interfering with their “ability to deal with his/her daily life activities”.
The authors also stressed the need – long recognized in ME/CFS and POTS – to employ some sort of cardiovascular stressor (standing, tilt table, exercise, etc.) to capture the full extent of the dysfunction in fibromyalgia.
Orthostatic intolerance has never been considered a major symptom in fibromyalgia, but findings suggesting that it is present in FM date back 20 years. With few studies examining the incidence of POTS, orthostatic hypotension or low blood volume in FM, there is still much to learn.
It’s possible, though, that fibromyalgia has less in common with pain disorders like arthritis than it does with diseases like ME/CFS and POTS, where cardiovascular issues produce problems with exercise, standing, fatigue, energy production, pain, cognition and sleep.
The evidence that autonomic dysregulation plays some role in FM appears strong. Numerous heart rate variability studies suggest that sympathetic nervous system hyperactivity – a key feature of hyperadrenergic POTS – is present in FM.
Other studies have documented that standing can increase symptoms, induce problems with blood pressure regulation, and abnormally increase heart rates. Finally, some studies suggest that low blood volume is present and that blood pooling may be occurring in FM patients’ lower bodies.
Recent findings, indicating that a small nerve neuropathy which results in the damage or disappearance of autonomic nerves is present in a substantial subset of FM patients, further implicates the ANS in FM – and opens up the issue of autoimmunity.
- Coming up next – Vital Motion – An FM doctor and biomedical engineer thinks he may be able to help with the cardiovascular problems in FM. Plus, “Could FM be an Autoimmune disease?”
Orthostatic Intolerance Resources
Check out the many resources on orthostatic intolerance in Health Rising’s Treatment Resource Section including:
- A Home Test for Orthostatic Intolerance / A Home Test for POTS / A Home Test for Hyperventilation.
- Traveling chair – Having trouble standing in lines? check out a lightweight travelling chair that can get you off your feet when you need to.
- Enhancing Blood Volume for Chronic Fatigue Syndrome (ME/CFS), POTS and Orthostatic Intolerance.
- Dr. Peter Rowe on Managing and Treating Orthostatic Intolerance
- Should Everyone with Chronic Fatigue Syndrome or Fibromyalgia Be Tested for Orthostatic Intolerance?
